Funkcje
|
AC/DC Prąd upływu, AC/DC pomiar prądu, On-line AC/DC pomiar prądu
|
Zasilanie
|
6F22,9V
|
Wyświetlacz
|
4 cyfry LCD
|
Wymiar cęgów
|
25mm×30mm
|
Wymiar miernika
|
175mm×70mm×38mm
|
LCD wymiary
|
35mm×21.5mm;
|
Próbkowanie |
2 razy/Sekunde
|
Częstotliwość
|
50Hz, 60Hz przełączana automatycznie
|
Zmiana zakresu
|
Automatyczna
|
Zakres
|
AC/DC:0.0A~1000A
|
Rozdzielczość
|
0.1A
|
Dokładność
|
±2%±3cyfry (23?±3?, poniżej 70%RH)
|
Napięcie
|
Poniżej AC 600V
|
RS232 Interfejs
|
zapisane dane mogą zostać przeniesione do komputera za pomoca interfejscu RS232 oraz oprogramowania
|
Pamięć
|
99 sets, “FULL” Blinking when memory is full
|
Peak Maintaining
|
Peak value capture hold function, press HOLD without Release to display peak value
|
Reading Hold
|
Reading hold function: “DH” symbol display
|
Overflow display
|
Range overflow function: “OL” symbol display
|
Automatic Shutdown
|
5 minutes after the boot
|
Battery Detection
|
When battery voltage is lower than 7.2V, low battery symbol will shown to remind battery replacement.
|
Meter Weight
|
180g (With battery)
|
Rated Power
|
10mW
|
Working Temperature and Humidity
|
0?~50?; below 80%rh
|
Max error refer to environment | -10?~0?,40?~50?,Error will increase max to 1%rdg. |
Storage Temperature and Humidity
|
-10?~60?; below 70%rh
|
Insulation Strength
|
AC2kV/rms (between core and box)
|
Safety Provisions
|
IEC1010-1, IEC1010-2-032, Pollution level 2, CAT ?(600V)
|
Accessories
|
Meter: 1 piece, RS232 Com-cable:1 piece; Software Disk: 1 piece; Battery (6F22 9V): 1 piece
|
