DC 40KV CAT II Pollution 2. |
2000MΩ Impedance. |
3999 LCD display. |
Accuracy 1.0% full range. |
T.C. 100 ppm/oC |
400V/4KV/40KV, 3 range. |
Resolution 0.1V/1V/10V. |
PEAK HOLD, Auto power off. |
CE, TUV GS, UL, CUL, IEC1010 |
SPECIFICATIONS ( 20 ± 5?, RH < 80% )
! WARNING !
? Before taking any measurements, first connect the alligator clip of this probe to earth ground and make sure connection is electrically good.
- Input impedance:2000MΩ
- Maximum operation voltage:40KV DC , CAT II , Pollution 2
- Polarity:Positive / Negative
- Display:3999 digital, LCD
- Accuracy:Full Range ? 1.0% ± 2 digital
- Temperature Coefficient:? 100ppm / ?
- Maximum loading Current:? 20μA
- Maximum loading power:? 0.8 watt
- Voltage Range:40KV / 4KV / 400V / 3 Range
- Voltage resolution:10V / 1V / 0.1V
- Power source:9V / 006P, IEC6L R1, NEDA 1604A
- Low battery Indicate:?7.3V Auto Indicate
- Battery Life:About 200hr ( ALKALI )
- Auto power off:About 30 mim
- PEAK HOLD:? 400 ms
- Sampling:4 Sampling / sec
- Operating temperature:0 ? ~ + 50 ?
- Storage temperature:- 20 ? ~ + 70 ?
- Ground lead length:90cm ( 35 " )
- Dimensions:420 L x 80ψ
- Weight:360g
